Tartaric Acid Esters of Mono- and Diglycerides
Tartaric Acid Esters of Mono- and Diglycerides of Fatty Acids, identified as E472d or INS 472d, are food-grade surface-active mixtures used to manage interactions between fat, water, air, proteins, starches and other formulation components.
E472d products are produced by esterifying food-grade mono- and diglycerides with tartaric acid under controlled manufacturing conditions. The resulting commercial material is not one pure molecule. It contains a distribution of tartaric-acid esters, glyceride structures and permitted residual components whose proportions determine functionality.
Grade performance depends on fatty-acid source, chain-length distribution, saturation, degree of esterification, mono- and diglyceride composition, acid value, melting profile, physical form and the complete food-processing system.
Product identity
| Full name | Tartaric Acid Esters of Mono- and Diglycerides of Fatty Acids |
|---|---|
| Short name | Tartaric Acid Esters of Mono- and Diglycerides |
| Common abbreviation | TARTEM may be used commercially; confirm supplier terminology |
| E number | E472d |
| INS number | INS 472d |
| Product category | Emulsifier and surface-active food ingredient |
| Chemical identity | Complex mixture of tartaric-acid esters of mono- and diglycerides derived from food fatty acids |
| CAS / formula | Mixture; no single universal formula adequately describes all commercial grades |
| Primary functions | Emulsification, interfacial control, fat dispersion, aeration support, texture management and process stabilization |
| Typical appearance | White, cream or pale-yellow powder, beads, granules, flakes, waxy solid or paste |
| Water behavior | Grade-dependent dispersibility or emulsifiability; typically not treated as a freely water-soluble ingredient |
| Fat behavior | Commonly incorporated through a warmed fat phase, melted premix or supplier-recommended dispersion |
| HLB behavior | Composition specific; request supplier application data rather than assuming one universal HLB value |
| Fatty-acid origin | Vegetable, animal or mixed origin depending on the selected commercial grade |
Potential industrial functions
- Reduces interfacial tension between oil and water phases
- Supports dispersion of fat through aqueous food systems
- Helps stabilize selected oil-in-water emulsions
- Can support selected water-in-oil fat systems
- Improves consistency of emulsifier distribution
- Supports air incorporation in compatible formulations
- Can influence gas-cell stability in bakery systems
- May modify crumb structure and eating texture
- Supports processing tolerance in selected applications
- Can be combined with other emulsifiers for tailored performance
How E472d functions at food interfaces
Mono- and diglyceride structures contain a lipophilic fatty-acid region and a more polar glycerol-derived region. Esterification with tartaric acid modifies the polarity, acid functionality and interfacial behavior of the glyceride mixture.
The emulsifier can orient at interfaces between fat and water or between air and the surrounding continuous phase. This may reduce interfacial tension and assist formation or stabilization of dispersed droplets, fat crystals or air cells.
Performance is highly formulation dependent. The same E472d grade can behave differently in bread dough, cake batter, margarine, frozen dessert, sauce, powdered mix or compound coating because each system has a different fat phase, water phase, temperature profile and mechanical process.
Oil-water interfaces
Surface-active molecules can position their lipophilic regions toward fat and their polar regions toward water, helping create smaller droplets and reducing immediate recoalescence.
Air-liquid interfaces
In compatible aerated systems, E472d may contribute to air-cell formation or stabilization. Actual overrun and foam stability also depend on proteins, sugars, hydrocolloids, fat crystals and mixing conditions.
Fat-crystal interactions
Emulsifier composition can influence fat nucleation, crystal distribution and interfacial coverage. The practical effect depends on the fat blend and cooling profile.
Starch and protein systems
Surface-active glyceride esters may modify interactions among fat, starch and protein. Texture effects should be established by controlled trials rather than inferred from E number alone.
Why commercial grades are not chemically identical
E472d is a mixture rather than a single purified compound. Differences in raw materials and reaction conditions produce grades with different melting behavior, polarity, acid value, fatty-acid distribution and functional performance.
| Composition variable | Potential effect |
|---|---|
| Fatty-acid chain length | Influences melting, lipophilicity and interfacial behavior. |
| Degree of saturation | Influences oxidative stability, melting profile and physical hardness. |
| Mono- and diglyceride ratio | Can alter polarity, crystal interaction and emulsification performance. |
| Degree of tartaric-acid esterification | Influences acid value, hydrophilic character and interfacial function. |
| Free tartaric acid | Can affect acidity, flavor, moisture sensitivity and analytical compliance. |
| Free glycerol | May influence moisture behavior and indicates the composition of the commercial mixture. |
| Residual mono- and diglycerides | Contribute their own emulsification and fat-crystal effects. |
| Physical processing | Spray cooling, flaking, granulation or milling influences particle size, flow and dispersion rate. |
Technical parameters to evaluate
E472d should be purchased against a signed specification linked to the required food-additive purity standard. Exact numerical limits vary by jurisdiction and manufacturer. The parameters below are specification categories rather than universal acceptance values.
| Parameter | Industrial significance | Purchasing guidance |
|---|---|---|
| Product identity | Confirms that the material is E472d rather than E472e, E472f or another glyceride ester. | Require the full chemical description, E number and applicable identification tests. |
| Acid value | Indicates the amount of free acidic functionality in the commercial material. | Specify the method, units and acceptable range. |
| Saponification value | Reflects the ester and fatty-acid composition of the mixture. | Use a controlled range when matching an approved grade. |
| Hydroxyl value | Indicates residual hydroxyl functionality and contributes to grade characterization. | Request where required by the applicable specification or internal equivalency standard. |
| Iodine value | Indicates the degree of fatty-acid unsaturation. | Useful for assessing source consistency, oxidation risk and physical behavior. |
| Total tartaric acid | Characterizes the tartaric-acid-derived portion of the emulsifier. | Confirm the analytical method and reporting basis. |
| Free tartaric acid | Affects acidity, taste, compliance and moisture behavior. | Include a maximum limit where required. |
| Total glycerol | Helps define overall glyceride composition. | Confirm whether the result is reported as glycerol equivalent. |
| Free glycerol | Indicates unesterified glycerol remaining in the product. | Include a maximum limit where specified by the relevant standard. |
| Total fatty acids | Defines the lipid-derived portion of the commercial mixture. | Request the supplier's test method and typical range. |
| Fatty-acid profile | Influences melting point, crystallization, source identity and application performance. | Specify key fatty acids or source consistency when technically important. |
| Mono- and diglyceride distribution | Can materially influence emulsification and fat-crystal behavior. | Request chromatographic or compositional data for critical applications. |
| Melting or softening behavior | Determines handling, incorporation temperature and final physical form. | Define the relevant melting point, slip point, drop point or softening method. |
| Moisture or loss on drying | Affects flow, caking, hydrolytic stability and active concentration. | Include a maximum value and analytical method. |
| Sulfated ash | Indicates inorganic residue. | Set a limit according to the applicable food-grade monograph. |
| Soap content | Residual soaps can influence pH, taste and emulsification. | Include a controlled limit where relevant. |
| Peroxide value | Indicates primary oxidation of lipid-derived components. | Use an appropriately low acceptance limit for oxidation-sensitive products. |
| Particle-size distribution | Influences flow, dissolution or dispersion rate and dry-blend uniformity. | Specify powder, granule, bead or flake dimensions. |
| Bulk density | Affects packaging volume, hopper capacity and feeder calibration. | Confirm whether loose or tapped density is required. |
| Lead | Critical elemental-contaminant parameter. | Include a specific maximum and approved analytical method. |
| Arsenic | May be controlled separately under food-additive standards. | Confirm the destination-market or customer limit. |
| Other elemental impurities | Cadmium, mercury or total heavy metals may be relevant. | Align limits with current market and customer requirements. |
| Residual solvents and catalysts | May be relevant to the selected manufacturing process. | Request a declaration and analytical limits where applicable. |
| Microbiological status | Low-moisture emulsifiers normally present limited microbial growth potential, but hygienic manufacture remains necessary. | Include limits where required by the intended application or customer policy. |
Selecting the correct commercial presentation
Fine powder
Powder grades may suit dry blending and rapid dispersion but can create dust and require controlled low-dose handling.
Granules or beads
Granular products may provide improved flow, reduced dust and more consistent automated feeding. Melting or dispersion time should be verified.
Flakes
Flakes are often convenient for melting into a warm fat phase. Their bulk density and melting rate can differ from powder or bead forms.
Paste or semi-solid grade
Paste formats may be designed for warm processing or blended emulsifier systems. Pumpability, storage temperature and segregation should be reviewed.
Carrier-based blend
A dry blend can simplify dosing or combine E472d with other emulsifiers, proteins, starches or carriers. Active content and full composition must be declared.
Application-specific system
Customized emulsifier systems may be designed for bread, cake, margarine, frozen dessert or powdered applications. Performance should be compared on cost-in-use rather than blend price alone.
Potential industrial food applications
Bread and fermented dough
- Pan bread
- Rolls and buns
- Flatbread systems
- Frozen dough
- Part-baked products
- Industrial bread improvers
Depending on grade and formulation, E472d may support emulsifier distribution, dough handling, gas-cell stability, crumb uniformity and production consistency.
Cakes and aerated bakery products
- Layer cakes
- Sponge cakes
- Muffins
- Whipped batters
- Bakery concentrates
- Powdered cake mixes
E472d may be evaluated as part of an aeration or emulsification system. Batter density, specific volume, cell structure and storage texture should be measured.
Margarine, spreads and shortening
- Table margarine
- Bakery margarine
- Low-fat spreads
- Water-in-oil emulsions
- Industrial shortening
- Fat-based fillings
Grade-specific products may support moisture distribution, emulsion integrity, plasticity and interaction with the fat-crystal network.
Frozen desserts
- Ice cream
- Non-dairy frozen desserts
- Frozen aerated desserts
- Frozen dessert premixes
In suitable blends, E472d may influence fat destabilization, aeration, overrun, body and meltdown. Homogenization and aging conditions remain critical.
Sauces and emulsified systems
- Emulsified sauces
- Dressings
- Fat-containing culinary bases
- Protein-fat emulsions
- Plant-based emulsified products
Emulsifier suitability depends on emulsion type, oil loading, droplet size, pH, protein, hydrocolloids, salt and thermal process.
Specialty fat and coating systems
- Compound coatings
- Fat-based confectionery fillings
- Wafer creams
- Seasoning-fat systems
- Powdered fat preparations
Flow, crystallization, coating behavior and compatibility with other emulsifiers must be validated for each fat system.
Dough, batter and crumb performance
Emulsifiers can influence multiple stages of bakery processing, including ingredient dispersion, fat distribution, air incorporation, gas-cell stability, starch behavior and eating texture.
E472d should not automatically be expected to reproduce the strong dough-conditioning behavior associated with E472e/DATEM. Grade performance must be evaluated directly in the target flour, recipe, mixer, proofing process and oven.
| Bakery variable | Potential E472d-related observation | Measurement |
|---|---|---|
| Dough development | Changes in mixing time, consistency or emulsifier distribution. | Mixer power, development time and dough temperature. |
| Dough handling | Changes in stickiness, machinability or tolerance. | Sheeting, dividing, moulding and line observations. |
| Proofing | Possible change in gas retention or proof tolerance. | Proof height, time and collapse resistance. |
| Loaf or cake volume | Possible effect on gas-cell stability and expansion. | Specific volume and dimensional profile. |
| Crumb structure | Possible change in cell size, uniformity and wall thickness. | Image analysis and trained visual assessment. |
| Crumb firmness | Possible change in initial softness and firmness development. | Texture analysis during real-time storage. |
| Sensory quality | Potential change in moistness, cohesiveness or waxy mouthfeel. | Trained panel and consumer-relevant assessment. |
| Slicing and packaging | Possible change in crumb resilience and damage. | Slice integrity, crumbling and package compression. |
Emulsion and crystallization control
Margarines, spreads, shortenings and fillings require control of both emulsion structure and fat crystallization. The emulsifier may affect droplet distribution, interfacial film, nucleation and the way the product responds during cooling and working.
| Process variable | Why it matters |
|---|---|
| Oil-to-water ratio | Determines the emulsion type, dispersed-phase load and interfacial area. |
| Fat composition | Controls melting profile, crystal form and compatibility with the emulsifier. |
| Emulsifier blend | Different emulsifiers may provide complementary interfacial and crystal-modification effects. |
| Premix temperature | Must be sufficient for uniform emulsifier distribution without unnecessary thermal exposure. |
| Agitation and shear | Influence droplet size and emulsion formation. |
| Cooling rate | Influences fat nucleation and crystal-network development. |
| Working conditions | Determine plasticity, crystal distribution and final structure. |
| Storage temperature | Affects post-crystallization, hardness, oiling and emulsion stability. |
Aeration, fat destabilization and meltdown
In frozen desserts, emulsifiers can displace proteins from fat-droplet surfaces and influence partial coalescence during freezing and whipping. This can support air-cell structure and body when the emulsifier is correctly balanced with the fat, protein and stabilizer system.
- Confirm E472d compatibility with the selected fat source.
- Evaluate the complete emulsifier blend rather than one ingredient alone.
- Control pasteurization temperature and holding time.
- Use validated homogenization pressure and stage configuration.
- Provide sufficient aging time for fat crystallization.
- Measure mix viscosity before freezing.
- Measure overrun and air-cell distribution.
- Evaluate fat agglomeration and dryness during extrusion.
- Measure meltdown, shape retention and serum drainage.
- Complete sensory testing for body, creaminess and waxiness.
Melting, dispersion and addition guidance
The correct incorporation procedure depends on the physical form and melting behavior of the selected E472d grade. The supplier's application instructions should take priority over a generic emulsifier procedure.
- Confirm the commercial grade. Identify whether the material is powder, bead, flake, paste or a diluted blend.
- Review the melting profile. Establish a processing temperature that provides uniform distribution without unnecessary overheating.
- Select the incorporation phase. Many grades are added to the warmed fat phase, while others are designed for dry blending or aqueous dispersion.
- Start effective mixing. Maintain sufficient circulation to prevent localized concentration or material settling.
- Add gradually. Avoid introducing large quantities into a cold or static portion of the batch.
- Confirm complete melting or dispersion. Inspect for flakes, beads, waxy particles or sediment before homogenization or transfer.
- Control water contact. Premature contact with water can create agglomeration or uneven emulsifier distribution in certain grades.
- Apply the required shear. Droplet size and emulsion formation depend on mixer and homogenizer performance.
- Control cooling. Emulsifier and fat crystallization continue during cooling and storage.
- Verify the finished product. Measure emulsion, texture, volume, aeration or flow properties after the complete process.
Compatibility with other functional ingredients
| Ingredient | Potential interaction | Development consideration |
|---|---|---|
| Mono- and diglycerides | May provide complementary emulsification, aeration and starch interaction. | Compare total emulsifier level and physical form. |
| DATEM / E472e | Has a different composition and may provide different bakery functionality. | Do not treat E472d and E472e as equivalent ingredients. |
| Lecithin | Can complement interfacial function and improve dispersion. | Review source, phospholipid composition and flavor. |
| Polysorbates | May contribute hydrophilic emulsification and aeration effects. | Verify market permission and combined dosage. |
| Sorbitan esters | May support lower-HLB or water-in-oil systems. | Balance against the target emulsion type. |
| Propylene glycol esters | May contribute aeration and fat-crystal functionality. | Compare melting profile and active composition. |
| Proteins | Compete for interfaces and influence emulsion stability. | Evaluate protein type, denaturation and homogenization. |
| Hydrocolloids | Increase continuous-phase viscosity and reduce droplet movement. | Control gum hydration and addition sequence. |
| Starches | Affect viscosity, water distribution and texture. | Evaluate the complete heating and cooling cycle. |
| Salts and minerals | Can affect proteins, interfacial films and emulsion stability. | Test using the actual water and mineral system. |
| Acids | May alter protein functionality and hydrolytic stability. | Validate pH, addition sequence and product shelf life. |
Recommended industrial trial measurements
| Trial stage | Measurements to consider |
|---|---|
| Incoming emulsifier | Appearance, odor, caking, particle size, melting behavior, lot coding and certificate-of-analysis compliance. |
| Melt or premix preparation | Melting time, clarity, sediment, temperature, viscosity and uniformity. |
| Emulsion formation | Droplet size, viscosity, creaming, separation and homogenization response. |
| Bakery mixing | Mixing time, dough temperature, consistency, stickiness and aeration. |
| Proofing and baking | Proof tolerance, volume, symmetry, crumb structure and bake loss. |
| Fat-system processing | Emulsion integrity, cooling curve, crystallization, plasticity and oiling. |
| Frozen dessert processing | Mix viscosity, overrun, extrusion behavior, fat destabilization and meltdown. |
| Finished texture | Firmness, cohesiveness, spreadability, creaminess, waxiness and mouthfeel. |
| Real-time shelf life | Separation, texture change, oil migration, staling, flavor and oxidation. |
| Regulatory verification | Final emulsifier level, carry-over, ingredient declaration and market compliance. |
Common processing observations
| Observation | Possible contributing factors | Areas to investigate |
|---|---|---|
| Undissolved or unmelted particles | Low temperature, short mixing time, incorrect addition phase or oversized flakes. | Review melting profile, particle size, temperature and agitation. |
| Emulsion separates quickly | Incorrect grade, insufficient dose, large droplets, low continuous-phase viscosity or unsuitable emulsion type. | Review grade selection, shear, homogenization and stabilizer system. |
| Oiling in fat-based product | Incompatible fat blend, poor crystallization, excessive temperature or inadequate emulsifier distribution. | Review fat composition, cooling, working and storage temperature. |
| Poor bakery volume | Unsuitable emulsifier functionality, weak flour, incorrect mixing, proofing or dosage. | Evaluate the complete bakery process and compare with E472e only through controlled trials. |
| Open or irregular crumb | Inconsistent mixing, unstable gas cells, water imbalance or poor ingredient distribution. | Review emulsifier incorporation, dough consistency and proofing. |
| Dense cake or low overrun | Inadequate aeration system, unsuitable emulsifier blend, cold fat or incorrect mixing sequence. | Review batter temperature, mixing speed, fat form and emulsifier blend. |
| Frozen dessert melts too quickly | Weak fat network, insufficient partial coalescence, low solids or unsuitable stabilizer-emulsifier balance. | Review fat, homogenization, aging, overrun and stabilizer system. |
| Waxy mouthfeel | Excess emulsifier, high-melting grade or incomplete integration. | Reduce dose, review melting profile and compare alternative grades. |
| Off-odor or rancid note | Oxidized fatty-acid raw materials, poor storage or excessive heat. | Check peroxide value, storage history, packaging and process temperature. |
| Powder cakes in storage | Moisture, heat, damaged liner, compaction or temperature cycling. | Improve packaging, warehouse conditions and pallet stacking. |
Fatty-acid, glycerol and tartaric-acid origin
The source of E472d raw materials can affect dietary suitability, customer acceptance, sustainability declarations, allergen review and supply-chain risk. The additive name alone does not establish whether a product is vegetable based, animal based, palm based or suitable for a specific certification program.
Fatty-acid source
- Palm or palm-kernel-derived fractions
- Rapeseed or canola-derived fatty acids
- Sunflower-derived fatty acids
- Soy-derived fatty acids
- Other vegetable sources
- Animal-derived fatty acids where applicable
Glycerol source
- Vegetable-derived glycerol
- Animal-derived glycerol
- Synthetic glycerol
- Mixed or variable origin
Tartaric-acid source
- Grape or wine-industry-derived material
- Other validated manufacturing routes
- Supplier-specific source declaration
Claims to verify
- Vegan or vegetarian suitability
- Halal certification
- Kosher certification
- Non-GMO status
- Palm-free declaration
- Certified sustainable palm sourcing
- Identity-preserved botanical origin
Food-category permission and labeling
E472d use is controlled by destination-market food-additive regulations. Permission, maximum levels, good-manufacturing-practice provisions and ingredient-list terminology may differ between food categories and countries.
The E472 series includes several chemically different additives. Regulatory and quality documentation should identify E472d specifically rather than referring only to “E472” or “tartaric emulsifier.”
Regulatory review
- Permission for E472d or INS 472d
- Permitted food category
- Maximum level or good-manufacturing-practice status
- Carry-over rules
- Ingredient-list designation
- Market-specific purity requirements
Identity controls
- Full additive name
- Correct E or INS number
- E472d versus E472e distinction
- Fatty-acid source
- Commercial blend composition
- Active emulsifier content
Supplier compliance
- Current signed specification
- Lot-specific certificate of analysis
- Traceability and recall capability
- Change-notification procedure
- Food-fraud and food-defense controls
- Third-party food-safety certification
Finished-food review
- Total emulsifier dosage
- Carry-over from compound ingredients
- Processing-aid versus additive status
- Dietary suitability claims
- Allergen and source declarations
- Export-market labeling
Powder, flake and molten-product precautions
Food-grade status does not remove occupational handling risks. Fine powders may create airborne dust, while molten or heated emulsifier can cause thermal burns. Workplace procedures should follow the supplier's current Safety Data Sheet.
- Minimize dust during bag opening and powder transfer.
- Use local exhaust ventilation where airborne particles may form.
- Wear suitable eye protection and work gloves.
- Use respiratory protection where required by risk assessment.
- Use heat-resistant protective equipment when handling molten product.
- Control the temperature of heated tanks, pipes and transfer hoses.
- Prevent water from entering hot fat or molten emulsifier systems.
- Keep away from incompatible oxidizing materials.
- Clean spills without spreading slippery or waxy residues.
- Follow confined-space and hot-work controls for bulk systems.
Documents to request before approval
- Current signed product specification
- Technical data sheet
- Lot-specific certificate of analysis
- Safety Data Sheet
- Food-grade compliance declaration
- E472d or INS 472d identity declaration
- Statement distinguishing the product from E472e/DATEM
- Applicable food-additive purity-standard declaration
- Acid, saponification, hydroxyl and iodine-value specifications
- Total and free tartaric-acid data
- Total and free glycerol data
- Fatty-acid profile
- Mono- and diglyceride composition where required
- Melting or softening specification
- Peroxide-value specification
- Elemental-contaminant limits
- Residual-solvent and catalyst declaration where relevant
- Country-of-origin statement
- Manufacturing-site statement
- Fatty-acid and glycerol source declaration
- Tartaric-acid source declaration where required
- Allergen and cross-contact declaration
- GMO statement where requested
- Vegan or vegetarian suitability statement
- Halal and kosher certificates where required
- Palm-origin or palm-free declaration where required
- Sustainable-palm certificate where applicable
- Food-safety certification and audit scope
- Packaging and food-contact compliance declaration
- Shelf-life and storage statement
- Traceability and recall procedure
- Change-notification policy
Industrial packing, storage and shipment
| Primary packaging | Multiwall paper bags, lined woven bags, cartons, drums or pails with a sealed food-grade inner barrier may be used. |
|---|---|
| Typical pack sizes | Commercial net weights depend on physical form and supplier. Confirm powder, flake, bead or paste packaging separately. |
| Container labeling | Product name, E number, grade, lot, net weight, production date, best-before date, storage conditions and supplier should be identifiable. |
| Storage temperature | Store under the supplier's specified cool and dry conditions, protected from excessive heat and temperature cycling. |
| Moisture protection | Maintain liner integrity to prevent caking, hydrolysis and contamination. |
| Heat protection | Excessive heat can soften flakes, deform beads, create blocking or cause paste separation. |
| Oxidation protection | Limit prolonged exposure to air, light, heat and reactive metals. |
| Palletization | Request pallet dimensions, bags or cartons per pallet, stacking limits, net and gross weight and stretch-wrapping details. |
| Transport | Vehicles and containers should be dry, clean, covered, odor-free and suitable for food ingredients. |
| Opened packaging | Reseal promptly, record the opening date and protect remaining material from moisture, heat and cross-contamination. |
| Stock rotation | Apply first-expired, first-out controls and retain complete lot-level traceability. |
Compare functionality and cost-in-use
E472d grades should not be compared only by price per kilogram. Composition, active content, physical form, melting behavior, dose, handling, process performance and finished-product yield can create significant differences in total cost.
A complete comparison may include:
- Delivered price per kilogram
- Active E472d concentration in the commercial product
- Required dose per tonne of finished food
- Acid, saponification and hydroxyl values
- Fatty-acid source and composition
- Melting and dispersion time
- Dust or handling loss
- Emulsion stability achieved
- Bakery volume and yield
- Crumb texture and shelf-life performance
- Aeration and overrun
- Fat-system plasticity or oiling control
- Compatibility with the existing emulsifier blend
- Required process changes
- Packaging and storage efficiency
- Batch-to-batch consistency
- Minimum order quantity
- Production and shipment lead time
- Documentation quality
- Technical application support
Information to include in a sourcing request
- Full product name and E472d designation
- Required INS designation where applicable
- Confirmation that E472e/DATEM is not requested
- Required food-grade or compendial standard
- Intended food application
- Target technical function
- Required acid-value range
- Required saponification-value range
- Hydroxyl- and iodine-value requirements
- Total and free tartaric-acid limits
- Total and free glycerol limits
- Fatty-acid profile or source requirements
- Vegetable, animal or specified botanical origin
- Melting or softening range
- Peroxide-value limit
- Powder, beads, granules, flakes or paste format
- Particle-size distribution
- Bulk-density and flowability requirements
- Target dosage
- Processing and incorporation temperature
- Required dietary or religious certifications
- Packaging format and net pack weight
- Trial quantity and annual demand
- Destination country and delivery address
- Preferred Incoterm
- Required shipment date
- Minimum remaining shelf life
- Required technical and regulatory documents
Recommended qualification workflow
- Confirm that E472d is permitted in the intended food and market.
- Define the required technical function and benchmark product.
- Issue a target chemical, physical and source specification.
- Review the supplier's regulatory, quality and safety documentation.
- Confirm that the offered product is E472d and not E472e or E472f.
- Obtain a representative sample of the proposed commercial grade.
- Verify appearance, odor, identity and certificate compliance.
- Test melting or dispersion using the intended process.
- Conduct a controlled benchmark against the current emulsifier.
- Measure emulsion, aeration, texture and processing performance.
- Complete pilot-scale production using commercial equipment.
- Evaluate real-time finished-product shelf life.
- Verify source claims, labeling and final additive dosage.
- Approve the final specification, packaging and use procedure.
- Compare the first commercial shipment with the approved sample.
- Establish routine certificate review and periodic verification testing.
Frequently asked questions
What are Tartaric Acid Esters of Mono- and Diglycerides used for?
E472d grades are used as emulsifiers and surface-active ingredients. Depending on composition, they may support fat dispersion, emulsion stability, aeration, bakery processing, texture and production consistency.
What is the E number for this emulsifier?
Tartaric Acid Esters of Mono- and Diglycerides of Fatty Acids are identified as E472d or INS 472d.
Is E472d the same as DATEM?
No. DATEM is E472e. E472d does not have the same acetylated tartaric-acid ester composition and should not automatically be substituted for DATEM.
Does E472d have one chemical formula?
No. E472d is a complex mixture whose molecules differ according to fatty-acid composition, glyceride distribution and degree of tartaric-acid esterification.
Is E472d soluble in water?
Most grades are better described as dispersible or emulsifiable than freely water soluble. Behavior depends on grade, temperature, particle size and formulation.
How should E472d be added to food?
Many grades are melted or dispersed in the warmed fat phase. Powdered or blended grades may use a different procedure. Supplier instructions and plant trials should determine the final method.
Can E472d be used in bread?
E472d may be permitted and technically suitable in selected bakery applications, but its effect depends on grade, flour, formula, dosage and process. It should not be assumed to perform exactly like E472e/DATEM.
Can E472d be used in margarine or spreads?
Grade-specific products may support water distribution, interfacial stability and fat-crystal processing. Suitability depends on the emulsion type, fat blend and cooling process.
Is E472d suitable for vegan products?
Suitability depends on fatty-acid, glycerol and processing-aid origin. A supplier-specific vegan or vegetable-origin declaration should be requested.
Is E472d palm free?
Not necessarily. Many food emulsifiers may use palm-derived fatty acids, while alternative botanical sources may also be available. Palm-free status must be confirmed for the exact product.
Which technical parameters should buyers compare?
Buyers may compare acid value, saponification value, hydroxyl value, iodine value, tartaric-acid content, glycerol content, fatty-acid profile, melting behavior, peroxide value, particle size and application performance.
Which documents should be requested?
Buyers should request a signed specification, certificate of analysis, Safety Data Sheet, E472d identity statement, source declarations, compositional data, contaminant limits, packaging specification, shelf-life information and relevant certifications.
Can Global Food Additives source different physical forms?
Global Food Additives can review powder, granular, bead, flake, paste and blended E472d grades according to composition, application, quantity, source requirements, destination, packaging and documentation.
Send your E472d specification and application details.
Include the required food-grade standard, target function, acid and saponification values, fatty-acid source, melting range, physical form, intended application, dosage, quantity, destination, packaging preference and documentation requirements. Our team will review your inquiry and respond from [email protected] .
Your message has been received. You will be redirected to the home page.
